Eddy current inspection is one of several NDT methods that use the principal of electromagnetism” as the basis for conducting examinations. Eddy currents are created through a process called electromagnetic induction. When alternating current is applied to the conductor, such as copper wire, a magnetic field develops in and around the conductor. This magnetic field expands as the alternating current rises to maximum and collapses as the current is reduced to zero. If another electrical conductor is brought into the close proximity to this changing magnetic field, current will be induced in this second conductor. Eddy currents are induced electrical currents that flow in a circular path. They get their name from “eddies” that are formed when a liquid or gas flows in a circular path around obstacles when conditions are right

One of the major advantages of eddy current as an NDT tool is the variety of inspections and measurements that can be performed. In the proper circumstances, eddy currents can be used for:

  • Crack detection
  • Material thickness measurements
  • Coating thickness measurements
  • Conductivity measurements for:
  • Material identification
  • Heat damage detection
  • Case depth determination
  • Heat treatment monitoring
